RA26
Speed 8s
Colour Blue WhiteKhakiRed WhiteBlack White
Weight 9kgs
$690
Ultralight, comfortable kids mountain bikes
Perfect performance, technology and unique style have always been the essential pursuit of cycling. The RA26, developed and designed by UNIQ, can meets all your requirements. The ultralight carbon fiber fork & aluminum frame give you a wind-like riding experience. Geometric body specially designed for kids & hidden inner wiring bring you the ultimate visual experience. Riding with UNIQ RA26, riding with confidence.
Geometric Data
Vehicle Configuration
Technical Details
Geometric Data
Tire/wheel size 26 inch
Horizontal tube length  528 mm
Steering angle 69°
Wheelbase 1017 mm
Seat tube angle 73°
Seat tube length 340 mm
Head tube length 120 mm
STACK 555 mm
REACH 370 mm
Vehicle Configuration
Frame
26 inch lightweight aluminum frame
Headset
Fully integrated 1" – 1 3/8" headset
Stem
Aluminum, Length:50 mm, Rise: +/-6°
Tyre
KENDA 26*1.75 ultralight inner and outer tires
Chainwheel
Forged 165 mm aluminium crank,34T
Rear derailleur
Shimano RD-M315SGS 1x8S
Saddle
Ergonomically designed to fit kid's anatomy
Chian
KMC X 9
Fork
26 inch ultralight carbon fork,1-3/8 stem taper
Handlebar
Aluminum, Width:600 mm, Rise:0mm
Wheel
26 inch double-chamber aluminum rims, G14 spoke, F:24H R:24H, F: 100x12 mm R:135x12 mm aluminum hubs with sealed industrial bearings
Brake
TEKTRO flat mounted mechanical disc brake, professional kid's brake handle, front and rear disc 140 mm
Freewheel
Shimano 8S 11-32T
Shift lever
Shimano SL-M310-R
Seat Post
Anodised 6061 aluminum,27.2x300L
