MC24
Speed 12S
Colour Blue PurpleSpartaPandora
Weight 8.8kg
$1371
Light, comfortable children bikes
Performance, technology and style has always been a cornerstone of cycling. We may not have competition, but we like the feel of the car - lightweight, fast, beautiful you. Professional athlete, weekend warrior, ostrava (with Strata) hunters and recreational riders have similar aspirations - we love of machines as well as their way of life.
Geometric Data
Vehicle Configuration
Technical Details
Geometric Data
Tire/wheel size 24x540
Steering angle 71°
Horizontal tube length 450mm
Wheelbase 890mm
Seat tube angle 73.5°
Seat tube length 340mm
Head tube length 105mm
STACK 624mm
REACH 321mm
Vehicle Configuration
Frame
24inch ultralight carbon frame Toray T700 Integrated molding process
Headset
Fully integrated 1" – 11/2" headset
Stem
Length:45L +0/-10
Tyre
VEE CROWN GEM 24*2.25  ultralight inner and outer tyre
Chainwheel
SRAM X1,155mm, 34T
Saddle
Ergonomically designed to fit children's pelvis Non-toxic Side protection to lean against walls
Chain
KMC X12
Shift lever
SRAM SX
Fork
24inch RST FIRST air suspension 80mm travel.
Handlebar
Width:600mm. Rise:0mm
Wheel
24inch double-chamber aluminum rims, CNC7075 Aluminum hubs with sealed industrial bearings. G14 spokes with F/R 24holes F:100x15mm R:142X12mm
Brake
TEKTRO Hydraulic disc brake, kid-frindly brake lever, front and rear disc 140mm.
Freewheel
SRAM PG 1030 12S 11-48T
Seat Post
27.2x300L, Anodised aluminum 7075
Rear derailleur
SRAM SX 1X12S
